Feature
· SFP VSE-7 MOA Etched Glass Reticle w/ 0.25MOA Illuminated Floating Dot, Christmas Tree Pattern for Fast Follow-Up Correction
· Fully Multi-Coated 50mm Objective Lens Improves Light Transmission for a Clear, Edge-to-Edge Sight Picture in Benchrest Shooting
· 30mm Tube Dia Enhances Elevation Range to 80 MOA, 1/4 MOA Click Value for Precise Adjustment, Side Focus Min from 10 Yds
· Elevation Zero Stop with Revolution Indicator Enables Easy Zero Return, While Windage Turret Lock Prevents Accidental Shift
Specification
| Specification | Details |
|---|---|
| Magnification: | 6-24x |
| Objective Lens Dia: | 50 mm |
| Focal Plane: | Second Focal Plane |
| Eye Relief: | 95 mm / 3.74 in |
| Lens Coating: | Fully Multi-Coated |
| Linear Field of View @ 100 yd: | 18.3-4.6 ft @ 100 yards |
| Linear Field of View @ 100 m: | 6.1-1.53 m @ 100 meters |
| Angular Field of View: | 3.5-0.88° |
| Reticle: | VSE-7 MOA |
| Tube Dia: | 30 mm |
| Side Focus: | 10 yards to Infinity |
| Click Value: | 1/4 MOA |
| Turret Function: | Elevation Zero Stop & Revolution Indicator; Windage Turret Lock |
| Elevation Adjustment Range: | ≥80 MOA |
| Windage Adjustment Range: | ≥50 MOA |
| Diopter Compensation: | -2 to +2 |
| Illumination Setting: | 6 Gears Red, On/Off Switch |
| Battery Type (Not Include): | CR2032 |
| Waterproof: | IPX4 |
| Fogproof: | Nitrogen Filled |
| Shockproof: | 750 G |
| Housing Material: | 6063-T6 Aluminum Alloy |
| Finish: | Matte Black |
| Length: | 354 mm / 13.94 in |
| Weight: | 728 g / 25.68 oz |
| Items in the Package: | User Manual, Plastic Wrench, Cleaning Cloth, Flip-up Caps, Hex Key, Sunshade, etc. |
Size
Reticle
